Crawler Mixer Truck

Crawler Mixer Truck

Introduction:

Crawler mixer trucks is concrete mixing and transportation equipment suitable for complex terrains. The crawler chassis enables to travel on various complex terrains, such as muddy farmland, rugged mountainous areas, soft sand, etc.

Add To Cart

Inquire Now

Introduction
Specification

Crawler mixer trucks is concrete mixing and transportation equipment suitable for complex terrains. The crawler chassis enables to travel on various complex terrains, such as muddy farmland, rugged mountainous areas, soft sand, etc. They can also turn flexibly in narrow spaces. They are particularly suitable for working on construction sites with height and width restrictions and places where wheeled vehicles are difficult to pass. They have strong mixing power and can mix concrete quickly and evenly to ensure the quality and performance of concrete. If the construction environment is not very good, crawler mixer truck is your top choice.

ITEM	CRAWLER MIXER TRUCK
Capacity	3m3
Engine	Yunnei 4102 turbo or customized
Brake system	Air brake
Steer system	Hydraulic steering
Water system	200L
Hydraulic system	Open circuit (closed circuit is optional)
Weight	4800kg
Crawler dimension	3500x2200x900mm
Overall dimension	5650x2000x2950mm
Tank material	BW300TP high strength wear-resistant steel, shot peening anti-rust treatment
Blade material	Alloy steel
Sealing end material	Alloy steel for both sealing ends.
